ABS Box Fiber Optical/Optic PLC Splitter 1X4 Sc to Sc Fiber Coupler with Sc/APC Upc Connector

Basic Info.

Model NO.	ABS BOX 1x4
Keywords3	Splitter PLC
Keywords4	Box PLC
Transport Package	1 PC/Blister Box
Specification	100x80x10mm
Trademark	Fibconet
Origin	Ningbo, China
HS Code	3903110000
Production Capacity	700, 000 PCS/Month

Product Description

ABS Box Fiber Optical/Optic PLC Splitter 1X4 sc to sc fiber coupler with Sc/APC UPC Connector

Planar light-wave circuit splitter (PLC Splitter) is a type of optical power management device that is fabricated using silica optical wave-guide technology.It is used to split a fiber optic beam into several beams at a certain splitting ratio.It is an important passive device in passive optical network.
APPLICATIONS
· FTTx
· Cable television (CATV)
· Local area networks (LAN)
· Test equipment
· Passive optical networks(PON)
FEATURE
· Wide operating wavelength range:from 1260nm to 1650nm
· Wide Operating Temperature: from -40ºC to 85ºC
· Good channel-to-channel uniformity
· High reliability and small size
· Adopt high strength stainless steel, pass salt spray test
· Adopt 100% new raw material, ROHS compliance
· Low Insertion loss&Low PDL Compact Design
SPECIFICATION OF PLC SPLITTER

1xN PLC Splitter Specification
Operating Wavelength(nm)	1260~1650
Fiber Type	G657A1 or as customers' order
Port Configuration	1x2	1x4	1x8	1x16	1x32	1x64	1x128
Insertion Loss (dB)	3.8/4.0	7.1/7.3	10.2/10.5	13.5/13.7	16.5/16.9	20.5/21.0	23.8/24.2
Loss Uniformity (dB)	0.4	0.6	0.8	1.2	1.5	2.0	2.5
Polarization Dependent Loss(dB)	0.2	0.2	0.2	0.25	0.3	0.35	0.4
Wavelength Dependent Loss(dB)	0.3	0.3	0.3	0.5	0.5	0.5	0.5
Temperature Dependent Loss (-40~85 ) (dB)	0.4	0.4	0.4	0.5	0.5	0.5	0.5
Return Loss (dB)			55/50
Operating Temperature			-40~+85
Directivity (dB)			≥ 55
Storage Temperature			-40~+85

2xN PLC Splitter Specification
Operating Wavelength(nm)	1260~1650
Fiber Type	G657A1 or as customers' order
Port Configuration	2x2	2x4	2x8	2x16	2x32	2x64	2x128
Insertion Loss (dB)	4.0	7.6	11.0	14.4	17.5	21.0	24.5
Loss Uniformity (dB)	0.6	1.0	1.2	1.5	1.8	2.2	2.5
Polarization Dependent Loss(dB)	0.2	0.2	0.3	0.3	0.35	0.4	0.4
Wavelength Dependent Loss(dB)	0.3	0.4	0.5	0.5	0.5	0.5	0.5
Temperature Dependent Loss (-40~85 ) (dB)	0.4	0.4	0.4	0.5	0.5	0.5	0.5
Return Loss (dB)			55/50
Operating Temperature			-40~+85
Directivity (dB)			≥ 55
Storage Temperature			-40~+85

Q: The History of our factory?
A: In 2000, Fibconet entered the communications industry and began to make adapters. It accumulated funds to invest in jumper production in 2006, and increased the optical splitter workshop in 2009. Fibconet won the national high-tech industry in 2013, and sold over 15 million US dollars in 2015, and began to explore foreign markets.
Q: The location of our factory?
A: Our factory is located in Ningbo, Zhejiang, and our new factory has also been put into production, located in the Northeast (Jilin Province).
Q: Occupied area for our factory ?
A: The construction area of our factory is about 23,000 square meters, including 8000 square meters in Fenghua Plant and 15,000 square meters in Northeast China.
Q: Production capacity for the PLC splitter?
A: 800,000 pcs per month.
Q:What's your best price for your passive fiber optic product?
A: Based on the quality of our products and the quantity of your estimated. We would quote the great best matching price all the time.
Q:Do you offer guarantee for the products?
A: Yes, we offer 1-2 years warranty to our formal products.
Q:What action will you take if there are some product problems?
A: If there are defective ones in the batch of products, we will offer spare ones for.
